Ormo skärmanläggning

Position 57°50,4'N 011°54,3'E; Chart 931

Barrage information

The barrage is unmanned and remotely controlled.

To request opening/closing of the barrage,
contact the barragewatch at +46(0)696 178 80

At the barrage there is two passages:

  • Passage for small craft with a horizontal clearance of 5m and a maximum depth of 1,8 - 1,2 m
  • Passage for bigger vessels with a horizontal clearance of 65 m and depth 5 - 4 m

Bridges

For passage to Göta Älv though Ormo-Kungälv the mariner have to pass three bridges:

  • Nordre älv Railway bridge
    Fixed bridge with vertical clearance: 12,5m

  • Kungälv Highway bridge
    Fixed bridge with vertical clearance: 12,5m

  • Nordre älv roadbridge
    Openable bridge with vertical clearance: 5,2m

Other information

To receive depth information see the water level gauge at entrance to the lock.
Be aware of the strong current in the area.

Last updated 2021-04-30
